Rockford Fosgate X317MAX-RSS 1,000 Watt Can-Am X3 MAX Rear Subwoofer Solution (Gen-3)

Plug-n-play system easily integrates into existing Rockford Fosgate aftermarket audio systems. Audio system is 100% Element Ready™ solution and provides ability to take your off-road vehicle into any environment. The subwoofer enclosures mount underneath the rear driver and passenger seats, and the amplifier mounts inside the rear center tunnel.  Amplifier also employs the Rockford Fosgate PRESET switch for easy set-up, allowing maximum performance without any tuning. System features a plug-and-play design and does not require any cutting or drilling of vehicle.  A step-by-step install video is available for DIY installations.

General Features:

• Bass upgrade for select Can-Am stage kits
• Uses factory mounting locations for easy install
• M2 10” IPX6 Element Ready™ loaded subwoofers in enclosures under rear seats
• Down firing configuration for improved performance
• Custom fit left and right sealed subwoofer enclosures
• Roto-mold design for lightweight and durable seamless construction
• Enclosure textured to match factory finish
• M5-1000X1: 1,000-watt mono IPX6 Element Ready™ amplifier
• Vehicle specific wiring harness and mounting plate for amplifier
• Amp PRESET engages Rockford Fosgate tune, eliminating need for manual setup

• Woofer Quantity: 2
• Woofer Size: 10"
• Woofer Series: M2D2-10IB
• Nominal Impedance (ea): 2Ω (4Ω each enclosure wired in parallel to create a 2Ω amp load)
• Frequency Response: 20 Hz – 750 Hz
• Sensitivity: 90.3 dB
• Power Handling (Watts RMS): 500 Watts RMS, 1,000 Watts Peak
• Enclosure Type: Infrasonic: 30 Hz @ 12dB/Octave
• Enclosure Type : Sealed
• Enclosure Material: Roto-molded HDPE
• Speaker Connector: 2-pin Deutsch™/Amphenol™
• Dimensions: 19.97” x 18.82” x 8.06” (each enclosure)
• Box (H x W x D): (608 cm x 573 cm x 245 cm)
• Wedge (H x W x D1 x D2): (608 cm x 573 cm x 245 cm)
